Lambretta Furgone Li 175 Series 2

  • Fli 175 (Series 2)
  • Fli 175 (Series 2) Half Cab

The Lambretta Furgone Li 175 Series 2.

Technical Specification

Model Fli 175 Series Two
Production Started July 1960
Production Ended June 1963
Frame Prefix T41 Extremely late machines M41
Engine Prefix FLI175
Starting Frame N° 450001
Starting Engine N° 420001 (However Late series 2 machines feature Lambro 175 Engines Starting around 450000)
Amount Produced 49499 (Presumed)
Engine 175cc, two stroke, 62x58mm, Inside cab
Power & Rate 7HP at 4,750RPM
Compression Ratio 1:7
Head & Cylinder Aluminium & Cast Iron
Engine Cooling Forced Air
Crankcase Oil SAE 90 1200grams
Starter Manual Lever
Kickstart
Clutch Multiple discs in oil bath
Gears 4 speed hand shifter and reverse
Gear Ratios 1st 1:28.050
2nd 1:16.107
3rd 1:10 .131
4th 1:6.875
Reverse 1:29.987
Ignition Magneto
Spark Advance 22°-24° 32-33mm on the circumfrance of the flywheel
Point Settings .35-.45mm
Sparkplug Bosch 225-240, long thread
Primary Gear
Secondary Shaft and differential
Transmission Oil SAE 90 180grams
Carburetor dell'orto MA19BS5 followed by MA19BS7
Carburation Main 80, Pilot 40, valve 60
Fuel Mix 4.00%
Fuel Consumption 1lt per 32km
Fuel Capacity 11.5lts
Range 275km
Maximum Speed 58-61km/h
Brake Type Front: Mechanically controlled drum
Rear: Hydraulically controlled drum
Tire 4.00 x 8 T
Tire Pressure Front: 2.0ATM
Rear: 3.25ATM
Front Oscillating connecting rods
Rear Rigid cross beam with longitudinal leaf springs
Dry Weight 255kg open trunk, 287kg closed compartment
Longitudinal Dimension 2,710mm
Transversal Dimension 1,330mm
Vertical Dimension Box 1,620mm
Max Hight 1,620mm
Ground Clearance 120mm
Wheel Base 1,710mm
Track Width 1,180mm
Minimum Turning Radius 1,605mm
Load Capacity 380-400kg
System 12 Volt with 18amp battery
Frame Steel tubing with 1,710mm resistence
Cab Round cab with single round headlight & canvas half back
From Frame N°489792 (A new non interchangable cab was introduced with conventional doors).
Floor mats as standard.
Doors Optional coach doors with windows upto Frame N°489792,
For replacent cabs and vehicles after Frame N°489793 optional conventional doors
Trunk Type Aluminum compartment
Aluminium pressed pickup trunk with hinged rear panel
Also available as chassis only
Colours Grey, Blue
Optional Extras Speedometer, Clock, Electric windshield wiper
Steering Handlebar
Accelerator Actuated by twisting of the right handle bar grip
Brakes Front: Foot pedal
Rear: Right lever on handlebar
Clutch Left lever on handlebar
Gears Actuated by twisting of the left handlebar grip with clutch engaged
Reverse by actuating lever on the centre column whilst not in motion with
clutch engaged and first gear selected
